Product Description
Semi-hermetic Screw Compressor: Equipped with world-class Bitzer or Hanbell compressors for high efficiency, low noise, and long service life.
Air-Cooled Condenser: Large-surface copper tube with aluminum fins ensures excellent heat dissipation without the need for cooling towers or water treatment systems.
Energy-Saving Design: Step-wise or stepless capacity control (12.5%–100%) adapts precisely to load changes, reducing power consumption.
Eco-Friendly Refrigerant: R134a (optional R407C/R404A) meets international environmental standards.
Advanced Protection System: Includes phase protection, overload protection, anti-freeze protection, high/low pressure switches, and water flow switches for maximum safety and reliability.
Easy Installation & Maintenance: Compact structure, no need for machine room; all maintenance can be performed from the front.
| Parameter | Specification |
|---|---|
| Cooling Capacity | 686 kW (200 Ton) |
| Power Supply | 380V/3Ph/50Hz (customizable) |
| Compressor Type | Semi-hermetic Screw (Bitzer/Hanbell) |
| Refrigerant | R134a |
| Condenser | High-efficiency air-cooled |
| Evaporator | Shell and tube |
| Total Power Input | Approx. 225 kW |
| Dimensions (L×W×H) | 4350 × 2150 × 2350 mm (approx.) |
| Weight | Approx. 5650 kg |
Perfect for large-scale industrial cooling needs, including:
Plastic injection molding & blow molding
Chemical & pharmaceutical processes
Food & beverage production
Metal plating and anodizing
Data centers and large commercial buildings
Extrusion lines and die casting
Over 20 years of professional refrigeration manufacturing experience
Exported to more than 70 countries with excellent after-sales reputation
CE and ISO9001 certified quality assurance
One-year warranty with lifetime technical support
Custom design available to meet specific voltage, refrigerant, or performance requirements
Get stable, efficient, and cost-effective cooling for your large industrial facility. Contact us today for a tailored quotation!
